| Wire Diamter | 1.8mm, 2.0mm, 2.5mm, 2.8mm,3.0mm, 3.5mm |
|---|---|
| Height | 2', 3', 4', 5', 6', 7', 8' |
| Length | 10', 15', 20', 30', 50',100'. |
| Item No. | clf-gal |
| Brand | Orange wire |
| Hole Size | 25mm x 25mm, 30mm x 30mm, 50mm x 50mm, 60mm x 60mm |
Chain link fence is also called diamond mesh fences, cyclone fences. The chain link wire mesh is formed by twisting wire raw material together. There are also two kinds of edges which are folded edges and twisted edges. The raw materials can be galvanized steel wire or PVC-coated steel wire. The latter one can have custom colors and the most popular one is dark green. It is available with:
• Galvanized or PVC coated — standard mesh or micromesh.
• Barbed wire and razor wire for added security protection.
• Anti-climb and anti-cut features for higher security.
•Suitable for many occasions,like backyard, children’s playgrounds, sport fields, recreational grounds.
| Material | Galvanized steel wire |
| Height | 0.5m-6m |
| Length | 4m-50m |
| Mesh Opening | 20*20mm,50*50mm, 60*60mm,80*80mm etc |
| Wire diameter | 1.0mm-6.0mm |
| Technique | Woven |
| Post & rail diameter | 32mm, 42mm, 50mm, 60mm, 76mm, 89mm etc |
| Post & rail thickness | 1.5mm, 2.0mm, 3.0mm, 4.0mm, 5.0mm etc |
| Post type | Round post, angle post, square post, etc |
| Edge type | Knuckle type, twist type, special type |
| Surface treatment | Electric galvanized, hot dipped galvanized, PVC coated |
Usage:Chain Link Fence is extensively used as fences for playground and gardens, super highway, railway, airport, port, residence, etc. Feature:With uniform mesh hole and flat surface, chain-link fence has the following advantages: beautiful appearance, great corrosion resistance, long service lifespan. Type:Classified by the surface treatment: Elector-galvanized chain-link mesh, Hot-dip galvanized chain-link mesh, PVC-coated chain-link mesh, PE-coated chain-link mesh, Stainless chain-link mesh.
